Automatic transfer switch БАВР ТС 19"



Description

БАВР ТС is designed for automatic changeover of power supply telecommunication load from the main circuit to backup one (DPP). БАВР ТС is designed to be installed in 19" rack.

Application area

Server and workstations, communications and data transmission, social facilities, industrial enterprises.

Certificates

Certificate of conformity № РОСС RUАГ79 ВО7826



Functions

- Control of voltage, frequency, rotation of phases of basic and backup network;

- Automatic changeover of consumers power supply from a basic input to the backup one if voltage values of primary input exceed fixed limits together with mechanical and electrical blocking of simultaneous switching;

- issuing the command to run the backup power unit, and changeover of power supply of consumers from the basic input to the backup one (from DPP) if voltage values of primary input exceed fixed limits;

- Protection by circuit breakers of inputs I and II against short circuits and overloads;

- Test operations;

- Control of good switch;

- The ability to change network settings and settings;

- Remote management and control. (Optional).





Technical specifications

Current type

1F/ 3F

Rated voltage, V.

230/400

Allowable operating insulation voltage of power circuits, V

660

Allowable impulsive insulation voltage of power circuits, kV

6

Allowable operating insulation voltage of control circuits, V

300

Allowable impulsive insulation voltage of control circuits, kV

4

Rated current, A

23/40/63/80/125

Rated frequency, Hz

50 or 60

Degree of protection in accordance with GOST 14254-96

IP

Overall dimensions, W x D x H mm

482,6х133х260
